Transparent Column Encryption with Postgres

2022-12-01

14 minute read

One of the more common questions we receive at Supabase is “how do I encrypt sensitive data”?

pgsodium's Transparent Column Encryption (TCE) is one of the safest ways, and can be used to encrypt one or more text columns in any number of tables. Using TCE, you can encrypt data so that it doesn't leak into logs as well as providing your users with row-level encryption.

To understand how TCE works, let's first do a deep-dive into an important encryption topic: key derivation.

👀 Transparent Column Encryption (TCE) is the foundational feature of the Supabase Vault, a safe and easy way to store encrypted secrets and other data in your Postgres database. Learn more about Supabase Vault

How Key Derivation Works

The current state-of-the-art in encryption libraries is libsodium.

libsodium offers a range of APIs for authenticated secret and public key encryption, key derivation, encrypted streaming, AEAD, various forms of hashing, and much more.

This powerful API is available to PostgreSQL using the pgsodium extension. pgsodium provides all the functionality of the full libsodium API, but previously it required developers to set up database encryption themselves, which remained a challenge even for those familiar with database administration.

To solve this problem, pgsodium now has a full key management API, primarily via the table pgsodium.key and the pgsodium.create_key() function. This key table contains no raw keys, but instead uses libsodium Key IDs to derive keys that are used internally for encryption. A key derivation function is used with an internal root key that is unavailable to SQL and not stored in the database, but rather managed by you externally using flexible scripts, or by Supabase automatically as part of our service offering.

The simplest way to use pgsodium to encrypt and decrypt data is to first create a Key ID. Valid Key IDs are stored in pgsodium in a special extension table, and they can be created using the pgsodium.create_key() function. This function takes a number of arguments depending on how it's used, but the simplest case is to create a new key with no arguments:


_11
select * from pgsodium.create_key();
_11
-[ RECORD 1 ]---+-------------------------------------
_11
id | eaa20d8c-c77c-4985-9f73-2a5f5d1f1e6d
_11
name |
_11
status | valid
_11
key_type | aead-det
_11
key_id | 2
_11
key_context | \x7067736f6469756d
_11
created | 2022-11-13 21:19:35.765823+00
_11
expires |
_11
associated_data |

This key can now be used with pgsodium encryption functions by its UUID (eaa20d8c-c77c-4985-9f73-2a5f5d1f1e6d). For example:


_10
select * from pgsodium.crypto_aead_det_encrypt (
_10
'this is the message', -- a message to encrypt
_10
'this is associated data', -- some authenticated associated data
_10
'eaa20d8c-c77c-4985-9f73-2a5f5d1f1e6d'::uuid -- key ID
_10
);

This produces the following encrypted “ciphertext” using the aead-det algorithm from the libsodium XChaCha20-SIV encryption function.


_10
-[ RECORD 1 ]-----------+---------------------------------------------------------------------------------------------------------
_10
crypto_aead_det_encrypt | \\x099baa820250d7375ed141f8f1936af384bc229f3de1010a6eff6ffdaf3998baffbae75b5cd83d1c469407ff2d3764a428b742

Now to decrypt the ciphertext, pass it to the decryption function with the same Key ID:


_10
select *
_10
from convert_from(pgsodium.crypto_aead_det_decrypt (
_10
'\\x099baa820250d7375ed141f8f1936af384bc229f3de1010a6eff6ffdaf3998baffbae75b5cd83d1c469407ff2d3764a428b742',
_10
'this is associated data',
_10
'eaa20d8c-c77c-4985-9f73-2a5f5d1f1e6d'::uuid
_10
), 'utf8');

Which recovers the original “plaintext” message:


_10
-[ RECORD 1 ]+--------------------
_10
convert_from | this is the message

In the above example, there is no raw key, only a Key ID which is used to derive the key used to encrypt the message and authenticate it with the associated data. In fact, it is impossible for a SQL user to derive the key used above, and if the Key ID is stored, then no encryption keys or decrypted information will leak into backups, disk storage, or the database WAL stream.

Transparent Column Encryption

As of pgsodium 3.0.0 and up, the extension offers a simple and declarative Transparent Column Encryption feature (TCE). This feature is now shipped with all Supabase projects. TCE allows you to specify encrypted columns within a table and generates a new view that “wraps” that table to decrypt the contents.

TCE works using two dynamically generated objects for tables that contain encrypted columns:

  • an INSERT UPDATE trigger that encrypts data when it is inserted or modified
  • a view that is created to wrap the table to decrypt the data when it is accessed

To “transparently” decrypt the table, access the dynamically generated view instead of the table. For every encrypted column in the table, the view will have an additional decrypted column that shows the decrypted result.

It's worth noting at this point that sometimes there is some confusion about handling encrypted data with TCE. The T stands for Transparent which means, you can always see decrypted data through the view, where the decrypted data can't be see is when stored on disk, or in pg_dumps, backups, WAL streams, etc. This is often called Encryption At Rest and is one layer in many that may be used to encrypt and protect your data.

Often Transparent encryption is understood to be “Transparent Disk Encryption” or “Full Disk Encryption”, this is where a drive is encrypted but reading and writing that drive is decrypted. TCE is similar to this, where data on disk is encrypted, but it is more fine grained, only particular columns are encrypted. The data is also encrypted in the sense that the table stored on disk contains encrypted data, without the view or the key, pg_dumps and backups still contain encrypted data, this is not possible with disk-only encryption.

For the moment TCE only works for columns of type text (or types castable to text like json). Soon we will also support bytea and possibly more as use cases and tests get better.

TCE uses one of PostgreSQL's lesser-known features: SECURITY LABEL. A security label can be thought of as a simple label which is attached to an object (a table, column, etc). Each label is scoped to an extension and that extension can provide security features depending on the label.

Let's see a simple example of using SECURITY LABEL to encrypt a column using pgsodium.

Note: We're using “credit cards” in our examples below, because they are very easy to understand. Please don't store credit cards in your Supabase database - we are not a certified PCI Service Provider.

One Key ID for the Entire Column

For the simplest case, a column can be encrypted with one Key ID which must be of the type aead-det (as created above):


_10
CREATE TABLE credit_cards (
_10
id bigserial primary key,
_10
credit_card_number text
_10
);
_10
_10
SECURITY LABEL FOR pgsodium
_10
ON COLUMN credit_cards.credit_card_number
_10
IS 'ENCRYPT WITH KEY ID e348034b-3f07-4878-aad6-000511d12826';

The advantage of this approach is simplicity - the user creates one key and labels a column with it. The cryptographic algorithm for this approach uses a nonceless encryption algorithm called crypto_aead_det_xchacha20(). This algorithm is written by the author of libsodium and can be found here.

Using one key for an entire column means that whoever can decrypt one row can decrypt them all from a database dump. Also changing (rotating) the key means rewriting the whole table.

One Key ID per Row

A more fine grained approach would be storing one Key ID per row:


_10
CREATE TABLE credit_cards (
_10
id bigserial primary key,
_10
credit_card_number text,
_10
key_id uuid not null DEFAULT 'e348034b-3f07-4878-aad6-000511d12826'::uuid
_10
);
_10
_10
SECURITY LABEL FOR pgsodium
_10
ON COLUMN credit_cards.credit_card_number
_10
IS 'ENCRYPT WITH KEY COLUMN key_id';

This approach ensures that a key for one user doesn't necessarily decrypt any others. While rows can share key IDs, they don't necessarily have to (unlike the first example above where one key id was used for the entire column). It also acts as a natural partition that can work in conjunction with Row Level Security to share distinct keys between owners.

Notice also how there is a DEFAULT value for the key_id. In a way, this gives you the best of both approaches - encrypting the column when a per-row key ID is not provided. The downside to this approach is that you need to store one key ID per row, which takes up more disk space (but that's cheap!).

One Key ID per Row with Nonce Support

The default cryptographic algorithm for the above approach uses a nonceless encryption algorithm called crypto_aead_det_xchacha20(). This algorithm has the advantage that it does not require nonce values, the disadvantage is that duplicate plaintexts will produce duplicate ciphertexts.

Nonces are some extra cryptographic context that is used in many cryptographic algorithms to produce different ciphertexts, even if the plaintexts are the same. The nonce does not have to be secret, but it does have to be unique. pgsodium comes with a useful function pgsodium.crypto_aead_det_noncegen() that will generate a cryptographically secure nonce for you, and in almost all cases it's best to use that function unless you know specifically what you are doing. In password hashing approaches, this is often similar to how a “salt” value is used to deduplicate password hashes.

Duplicate ciphertexts cannot be used to “attack the key”, it can only reveal the duplication. However, duplication is still information. In our examples so far, an attacker might be able to use this information to determine that two accounts share the same credit card number. While not technically breaking the encryption, this still leaks information to an attacker.


_10
CREATE TABLE credit_cards (
_10
id bigserial primary key,
_10
credit_card_number text,
_10
key_id uuid not null DEFAULT 'e348034b-3f07-4878-aad6-000511d12826'::uuid,
_10
nonce bytea default pgsodium.crypto_aead_det_noncegen()
_10
);
_10
_10
SECURITY LABEL FOR pgsodium
_10
ON COLUMN credit_cards.credit_card_number
_10
IS 'ENCRYPT WITH KEY COLUMN key_id NONCE nonce';

This is the most secure form of TCE - there is a unique key ID and a unique nonce per row.

One Key ID per Row with Associated Data

The encryption that is used for TCE is one of a family of functions provided by libsodium to do Authenticated Encryption with Associated Data or AEAD Encryption. The “associated” data is plaintext (unencrypted) information that is mixed into the authentication signature of the encrypted data, such that when you authenticate the data, you also know that the associated data is authentic.

AEAD is helpful because often you have metadata associated with a secret, which isn't confidential but must not be forged.

In our credit card example, we might associate a "credit_card_number" with an "account_id". But what if a malicious actor wanted to use someone else's credit card on their own account? If someone could forge the account_id data column, swapping an account_id with their own account_id, then you could be tricked into using the wrong credit card. By “associating” the account_id with the credit_card_number, it cannot be forged without throwing an error.

Like above, this is done simply by extending the security label with the associated data column:


_11
CREATE TABLE credit_cards (
_11
id bigserial primary key,
_11
credit_card_number text,
_11
account_id integer,
_11
key_id uuid not null DEFAULT 'e348034b-3f07-4878-aad6-000511d12826'::uuid,
_11
nonce bytea default pgsodium.crypto_aead_det_noncegen()
_11
);
_11
_11
SECURITY LABEL FOR pgsodium
_11
ON COLUMN credit_cards.credit_card_number
_11
IS 'ENCRYPT WITH KEY COLUMN key_id ASSOCIATED (account_id) NONCE nonce';

The new label indicates which column is to be associated with the secret, and that's it! Your account_id and credit card number are now protected under the same authentication signature as the secret itself.

Using an Encrypted Table

Now that you have TCE setup for a table, it's easy to use by simply inserting data into the table, and querying that data by looking at its generated view. The view is named decrypted_<table_name> and by default is in the same schema as your table:


_10
insert into credit_cards
_10
(credit_card_number, account_id)
_10
values
_10
('1234-5678-8765-4321', 123);

Now that you have inserted data, look at the table and notice how the credit card number is encrypted. This is the data that is stored on disk, the encrypted card number, the key id, and the account id, but the key itself is not stored. This means if someone gets a backup or dump of your database, they cannot decrypt the credit card number, they do not have the key, only the key ID:


_10
> select * from credit_cards where account_id = 123;
_10
-[ RECORD 1 ]------+---------------------------------------------------------------------
_10
id | 1
_10
credit_card_number | jf8KfImkKTr+j4gzyDZQtLDEFL9eSlFuKjNlNEJvDg+OIKUr2wjF/8NnYcLisb5F9xiN
_10
account_id | 123
_10
key_id | 7f753c4f-8c68-457a-8801-1798b2e9f44d
_10
nonce | \x300a14aa721184ff7cf0f6bf088da267

For you, the developer, you need the unencrypted credit card number for you application. No problem, you can access that data using the dynamically generated decryption view decrypted_credit_cards:


_10
> select * from decrypted_credit_cards where account_id = 123;
_10
-[ RECORD 1 ]----------------+---------------------------------------------------------------------
_10
id | 1
_10
credit_card_number | jf8KfImkKTr+j4gzyDZQtLDEFL9eSlFuKjNlNEJvDg+OIKUr2wjF/8NnYcLisb5F9xiN
_10
decrypted_credit_card_number | 1234-5678-8765-4321
_10
account_id | 123
_10
key_id | 7f753c4f-8c68-457a-8801-1798b2e9f44d
_10
nonce | \x300a14aa721184ff7cf0f6bf088da267

Notice how there is a new column called decrypted_credit_card_number. This column is not stored in database or on disk at all, it is generated “on-the-fly” as you select from the view. Database dumps do not contain this information, only the view itself, and most importantly, raw decryption keys are never stored.

Future possibilities

We're always thinking about the future possibilities for features and tools that we can bring to the PostgreSQL community, and we'd love to hear from you about what kind of encryption features you'd like to see. Some things we've considered but not yet explored yet are:

  • Built-in Key Management Server (KMS) with REST API ala AWS or GCP.
  • Seamless Integration with external KMS services for key management.
  • Signcryption-based Token formats for exchanging AEAD tokens.
  • End-to-End encryption for user data using libsodium's crypto_secretstream() API.
  • Group encryption using signcryption
  • Your idea here?

There's a lot of potential in the world of cryptography with Postgres and pgsodium, and we'd love to hear any ideas you may have as well. Join us in our Discord #encryption channel if you want to chat more about it with us!
